Rugged Embedded Computing Solutions From

Extreme Engineering Solutions


As a leader in the design, manufacture, and support of
embedded computing solutions for compute-intensive military,
communications, commercial, and industrial applications,
X-ES provides a product portfolio of commercial-grade to
fully ruggedized boards and systems, including
Commercial Off The Shelf (COTS) products and fully-custom solutions.


View X-ES Embedded Products

Featured X-ES Products

6U VME SBC

XCalibur1931

The XCalibur1931 provides up to 8 GB of DDR3-1866 ECC SDRAM, two PrPMC slots, and 512 MB of NOR flash (with redundancy). It also supports six Gigabit Ethernet ports, PMC I/O, and RS-232/422/485 serial ports out the P2 backplane connectors.

It features an innovative Xilinx Artix-7 FPGA-based VME Bridge.

Learn More
3U VPX SBC

XPedite7572

The XPedite7572 is an optimal choice for computationally-heavy applications requiring maximum data and information protection. With integrated SecureCOTS™ technology, the XPedite7572 protects data from being modified or observed and provides an ideal solution when stringent security capabilities are required.

Learn More
Embedded Box PC

XPand6903

The XPand6903 provides a reliable and maintenance-free, cost-effective, computing platform ideally suited for environmentally challenging and space-constrained situations. It was specifically designed for Industrial PC (IPC), Human Machine Interface (HMI), industrial automation, and transportation applications, and its sealed design makes it ideal for medical and food-safe environments where it will be exposed to chemicals and moisture.

Learn More
3U VPX SBC

XPedite7670

The XPedite7670 is a high-performance, 3U VPX-REDI, single board computer based on the Xeon® D processor. The Intel® Xeon® D processor can provide up to eight Xeon®-class cores in a single, power-efficient System-on-Chip (SoC) package. The XPedite7670 maximizes network performance with two 10 Gigabit Ethernet interfaces and four Gigabit Ethernet interfaces.

Learn More

View the full selection of X-ES Embedded Products

View All Products

Rugged & Ready for Anything

X-ES rugged systems are designed for maximum performance in the most extreme environments imaginable.

Available in Small Form Factor (SFF) and ATR chassis types, these systems are capable of supporting 3U VPX, XMC, PMC, and COM Express® form factors, as well as custom modules.

Built and tested to meet the rigorous standards of MIL-STD-810F/G and DO-160 while integrating the latest power-saving and performance-enhancing technology, X-ES is sure to have a rugged chassis or fully-packaged Intel® Core™ i7-based system to match your requirements.

Explore Rugged Systems

Advanced Computing & Dependability When You Need It Most

X-ES embedded boards and systems are built on cutting-edge processor technology and adhere to a variety of industry standards, including VITA and PICMG.

Our products are fully designed, manufactured, tested, and supported in the United States, and are backed by our unique four-hour support guarantee – contact our talented support team, and you will hear back from us within four business hours.

X-ES takes your project seriously, and this is our commitment to you.

See the X-ES Difference

News & Events

News /

X-ES Announces a Xilinx Artix-7 FPGA-Based VME Bridge

Middleton, WI — Tuesday, January 26th, 2016

Extreme Engineering Solutions, Inc. (X-ES) announces several new 6U VME SBCs featuring a Xilinx Artix-7 FPGA-based VME Bridge. These 6U VME products are designed to be pin-compatible with the Radstone/GE/Abaco PPC7D VME IDT Tsi148-based card, providing users with a straightforward, disruption-free upgrade path for legacy systems and a solution to End-of-Life (EOL) VME products that included the now obsolete Tsi148 VME Bridge.

X-ES selects an FPGA-based VME solution enabling high performance VMEBus capability on our flagship SBCs. Offering a wide variety of valuable features beyond what the Tsi148 VME Bridge had been capable of, the Xilinx Artix-7 VME Bridge supports a x4 PCI Express 2.0 to the host interface and supports an external DDR3 SDRAM DMA buffer.

With its firmware upgradeable design and support for future portability of IP to a new chip, X-ES VME boards offer system integrators a VME Bridge solution devoid of components subject to lifecycle concerns, in an even smaller chip package than had previously been available.

Featured VME Products

XCalibur1931 & XCalibur1930 NXP 6U VME SBCs

The XCalibur1931 and XCalibur1930 both feature the NXP T2080 QorIQ communications processor alongside a Xilinx Artix-7 FPGA-based VME Bridge solution. Both are designed to address the EOL of the IDT/Tundra Tsi148. The Xilinx FPGA based VME bridge provides a means to mitigate obsolescence and ensure a long product lifetime.

The XCalibur1931, with its Radstone/GE/Abaco PPC7D-compatible pinout and NXP QorIQ T2080 processor coupled with up to 8 GB of DRAM, along with up to 32 GB NAND flash and two XMC/PMC sites, provides a significant performance boost over the PowerPC 7447.

The XCalibur1930 is the latest in X-ES’ line of PowerPC VME SBCs. It was designed to provide our existing customers with an upgrade path from X-ES’ previous VME offerings.

Both the XCalibur1931 and XCalibur1930 utilize the same Xilinx Artix-7 FPGA based VME bridge. The bridge supports all of the VME transfer modes from VME32 up through 2eSST320, providing drop-in compatibility or performance boost.

XCalibur4531 Intel® 6U VME SBC

The XCalibur4531 is a 5th Generation Intel® Core™ i7 6U VME SBC featuring a Xilinx Artix-7 FPGA-based VME bridging solution. By implementing an FPGA-based VME bridge, the XCalibur4531 mitigates obsolescence concerns prevalent in aging VME systems. XCalibur4531 supports VME32, VME64x, and 2eSST operation so it easily integrates into existing VME systems, making it the optimal choice to give your application a processing performance boost.

XCalibur4531 supports up to 16 GB ECC SDRAM, 64 GB onboard SSD storage, and hosts two XMC or PMC modules. XCalibur4531 is available in both air- and conduction-cooled assemblies with standard I/O interfaces including serial, video, USB, Ethernet, and SATA.

XChange4003 6U VME Carrier

The XChange4003 is a VME64x carrier card that facilitates connectivity of XMC/PMC modules to the VMEBus, by utilizing a Xilinx Artix-7 FPGA-based VME bridging solution. The FPGA-based VME bridge solution assures long production life and high performance operation.

XChange4003 supports all deployed versions of the VMEBus protocol, from the original VME32 up through VME64x and 2eVME/2eSST operation, making it an effective solution for interfacing any XMC/PMC module to any system’s VMEBus backplane.

XChange4003 supports both intelligent (Monarch PrPMC/Root Complex PrXMC) and non-intelligent (PMC/endpoint XMC) boards, and can operate in a SYSCON or non-SYSCON VMEBus slot.
