Embedded Computing Applications

CompactPCI Products

X-ES provides a comprehensive line of 3U CompactPCI (cPCI) and 6U cPCI products, including Intel® cPCI, PowerPC cPCI, and QorIQ cPCI Single Board Computers (SBCs), carriers, I/O cards, development platforms, and deployable systems for embedded computing applications. With both air-cooled and conduction-cooled boards and systems, these products can be applied to a wide variety of embedded applications across military, communications, and commercial/industrial markets.

Explore Products

3U cPCI SBCs

XPedite7530 3U cPCI SBC

X-ES provides 3U cPCI Single Board Computers based on the latest Intel® and NXP QorIQ processors. These Single Board Computers from X-ES have a wide variety of features, including up to 16 GB DDR3L of memory, an XMC/PMC mezzanine, one or two Gigabit Ethernet ports, USB 2.0 ports, SATA, serial, and much more.

View 3U cPCI SBCs

6U cPCI SBCs

XCalibur4501 6U cPCI SBC

X-ES provides 6U cPCI Single Board Computers based on the latest Intel® and NXP QorIQ processors. These Single Board Computers from X-ES have a wide variety of features, including up to 16 GB DDR3L of memory, two XMC/PMC mezzanines, up to five Gigabit Ethernet ports, USB 2.0 ports, SATA, serial, and much more.

View 6U cPCI SBCs

3U cPCI Power Supplies

XPm2010 3U cPCI Embedded Power Supply

High-performance and extremely rugged 3U cPCI embedded Power Supplies from X-ES enable integrators to reduce the SWaP, cost, and complexity from their system. These PICMG 2.11 power supplies have been designed to take in a MIL-STD-704 28 VDC input voltage and provides up to 300 W on 3.3 V, 5 V, and ±12 V at up to 90% efficiency.

View 3U cPCI Power Supplies

cPCI Rugged Systems

XPand4200 Series Rugged System

X-ES provides a line of high-performance, rapid-development 3U cPCI Rugged COTS-based systems. These natural convection-cooled or conduction-cooled, fully-ruggedized chassis are designed to meet the rigorous standards of MIL-STD-810, MIL-STD-1553, and ARINC 429 while integrating the latest power-saving and performance-enhancing technology.

View cPCI Rugged Systems

cPCI Development Systems

XPand1301 3U cPCI Development Platform

Our 3U CompactPCI Development Systems have features including momentary push button for reset, DC power enable switch, ATX, RJ-45 Ethernet, eSATA, and HDMI connectors, and slots for cPCI SBCs, a Cisco IOS® router, and power supplies, X-ES is sure to have a cPCI Development Systems solution to meet your needs.

View cPCI Development Systems

3U cPCI Routers

Cisco 5940 Rugged 3U cPCI Router

X-ES provides 3U CompactPCI Embedded Services Routers (ESRs) that are optimized for mobile and embedded networks that require IP routing and services.

It is capable of providing highly secure data, voice, and video communications to stationary and mobile network nodes across wired and wireless links, even in the harshest environments under intense shock and vibration conditions from rugged terrain.

View 3U cPCI Routers

3U cPCI Backplanes

XTend3130 3U cPCI Backplane

X-ES provides 3U CompactPCI backplanes that are designed to provide a low-cost and compact platform for up to eight cPCI modules and up to two VITA 62 power supplies.

They include one 3U cPCI system controller slot, seven 3U cPCI peripheral slots, support for up to two DC-DC power supplies, and a 32-bit PCI bus.

View 3U cPCI Backplanes

3U cPCI Carriers

XChange1200 3U cPCI Carrier

X-ES provides 3U CompactPCI Carrier Card solutions. These cPCI carriers provide easy integration of standard mezzanine cards into modern CompactPCI backplanes.

Our cPCI Carriers include features like PICMG 2.1 Hot Swap support, PICMG 2.3 PMC I/O to J3 and J5, PICMG 2.9 dedicated IPMI controller, PICMG 2.16 1000BASE-T Ethernet ports, PCI-X PMC slots, and a variety of Board Support Packages to choose from.

View 3U cPCI Carriers

3U cPCI RTMs

XIt1033 3U cPCI RTM

X-ES provides 3U cPCI Rear Transition Modules (RTMs) that enable I/O expansion and access for a variety of X-ES products, such as 3U cPCI SBCs and cPCI Backplanes.

Features include access to Gigabit Ethernet ports, PICMG 2.16 Ethernet ports, RS-232 serial, SATA, and USB 2.0 ports.

View 3U cPCI RTMs

6U cPCI RTMs

XIt4103 6U cPCI RTM

X-ES provides 6U cPCI Rear Transition Modules (RTMs) that enable I/O expansion and access for a variety of X-ES products, such as 6U cPCI SBCS and cPCI Backplanes.

Features include access to as many as 18 Gigabit Ethernet ports, PICMG 2.16 Ethernet ports, dual-link DVI port for graphics, audio I/O ports, micro-DB-9 connectors, RJ-45 connectors, RS-232/422/485 serial, SATA, and USB 2.0 ports.

View 6U cPCI RTMs
