XMC NETWORKING MODULE · SKU 90015350
XPort3309
The XPort3309 is a conduction- or air-cooled dual 10GBASE-T Ethernet XMC with front panel or rear I/O support. A x4 PCI Express Gen4-capable interface is routed per VITA 42.3 to the P15 connector for interfacing with the host module.
Product Lifecycle
X-ES also offers comprehensive configuration and obsolescence management services, providing customers with direct control over non-interchangeable changes and extending product availability and serviceability well beyond standard end-of-life milestones.
Engineered for Extended Reliability
All X-ES products are designed and manufactured 100% in the USA with components from trusted supply chains in order to deliver rugged, reliable performance in the most demanding environments.
Built with components rated for extreme conditions and validated through rigorous testing, our solutions minimize obsolescence risk and lower total cost of ownership across the full program lifespan.
Introduction to XPort3309
The XPort3309 is a conduction- or air-cooled dual 10GBASE-T Ethernet XMC with front panel or rear I/O support.
A x4 PCI Express Gen4-capable interface is routed per VITA 42.3 to the P15 connector for interfacing with the host module.
I/O Configuration
Front panel I/O for the 10GBASE-T ports is provided with up to two RJ-45 connectors.
The XPort3309 supports rear 10GBASE-T I/O through the P16 connector and utilizes X12d I/O mapping per VITA 46.9.
Ethernet Capabilities
The module utilizes automatic negotiation down to 100BASE-TX and 1000BASE-T on both 10GBASE-T ports.
The XPort3309 can also support IEEE 1588.
Ethernet Controller
- Intel® E610 dual 10 Gigabit Ethernet controller
- IEEE 1588 support
- SR-IOV support
Rear I/O Configuration Option
- Dual 10GBASE-T Ethernet ports to P16
- X12d mapping per VITA 46.9
Front Panel I/O Configuration Option
- Dual 10GBASE-T Ethernet ports to RJ-45 connectors
- Available in air-cooled configurations only (contact factory for details)
XMC
- x4 PCI Express Gen4-capable interface per VITA 42.3
- VITA 42 or VITA 61 connector build options (contact factory for details)
Environmental Requirements
Contact factory for appropriate board configuration based on environmental requirements.
- Supported ruggedization levels (see the X-ES Ruggedization Chart): 5
- Contact factory for air-cooled options
- Conformal coating available as an ordering option
Software Requirements
- Linux drivers
- Microsoft Windows drivers
- Contact factory for availability of Wind River VxWorks drivers
Power Requirements (Estimate)
- <10 W
Accessories
- XIt3114 (90060300) – 10GBASE-T XMC I/O Module (XIM) for XPort3309 and other XIM carriers
XPort3309
Conduction- or Air-Cooled XMC Network Interface Controller with Dual 10 Gigabit Ethernet Ports
