The XCalibur1935 is a high-performance, 6U VME, multiprocessing, single board computer that is ideal for systems requiring high bandwidth processing and low power consumption. It is a design refresh of the XCalibur1931, intended to update obsolete components while maintaining the same functionality and features. With four dual-threaded e6500 cores running at up to 1.8 GHz, each with a 128-bit AltiVec SIMD unit, the XCalibur1935’s NXP QorIQ T2080 processor delivers enhanced performance and efficiency for today’s embedded computing applications.
The XCalibur1935 provides up to 8 GB of DDR3 ECC SDRAM, two XMC/PrPMC interfaces, and 512 MB of NOR flash (with redundancy). It also supports up to six 10/100/1000BASE-T Ethernet ports, PMC I/O, and RS-232 serial ports via the P2 backplane connectors. The front panel offers two 10/100/1000BASE-T Ethernet ports, RS-232 serial, and an optional USB 2.0 port.
The XCalibur1935 is a powerful, feature-rich solution for the next generation of compute-intensive embedded applications. Wind River VxWorks, Linux, and Green Hills INTEGRITY Board Support Packages (BSPs) are available.
Technical Specs
Processor
- NXP QorIQ T2080 processor
- Four dual-threaded e6500 cores at up to 1.8 GHz
- 2 MB of shared L2 cache
Memory
- Up to 8 GB of DDR3 ECC SDRAM
- Up to 512 MB of NOR flash (with redundancy)
- Up to 32 GB of NAND flash
- NVMe storage (optional)
VME
- VME64 (VITA 1-1994 R2002)
- VME64x (VITA 1.1-1997 R2003)
- 2eSST (VITA 1.5-2003)
- Ethernet on VME64x (VITA 31.1-2003)
- PMC I/O on VME (VITA 35-2000)
XMC/PrPMC
- PCI-X (64/32-bit, 100/66 MHz)
- PCI (64/32-bit, 66/33 MHz)
Back Panel
- Two RS-232 serial ports
- Up to six 10/100/1000BASE-T Ethernet ports
- PMC I/O
- Two-channel 1553 (optional)
Front Panel I/O
- Two RS-232 serial ports
- One or two 10/100/1000BASE-T Ethernet ports
- One USB 2.0 port (optional)
Software Support
- Wind River VxWorks BSP
- Linux BSP
- Green Hills INTEGRITY-178 BSP
- Contact factory for availability of QNX Neutrino and LynuxWorks LynxOS BSPs
Environmental Requirements
Contact factory for appropriate board configuration based on environmental requirements.
- Supported ruggedization levels (see the X-ES Ruggedization Chart): 1, 5
- Conformal coating available as an ordering option
Power Requirements
- Power will vary based on configuration and usage. Please consult factory.
