6U CompactPCI SINGLE BOARD COMPUTER · SKU 90055100
XCalibur1903
The XCalibur1903 is a high-performance 6U cPCI single board computer supporting an NXP QorIQ T2080 processor. It is a design refresh of the XCalibur1900, intended to update obsolete components while maintaining the same functionality and features.
Product Lifecycle
X-ES also offers comprehensive configuration and obsolescence management services, providing customers with direct control over non-interchangeable changes and extending product availability and serviceability well beyond standard end-of-life milestones.
Engineered for Extended Reliability
All X-ES products are designed and manufactured 100% in the USA with components from trusted supply chains in order to deliver rugged, reliable performance in the most demanding environments.
Built with components rated for extreme conditions and validated through rigorous testing, our solutions minimize obsolescence risk and lower total cost of ownership across the full program lifespan.
Introduction to XCalibur1903
The XCalibur1903 is a high-performance 6U CompactPCI single board computer supporting an NXP QorIQ T2080 processor.
Design Refresh
It is a design refresh of the XCalibur1900, intended to update obsolete components while maintaining the same functionality and features.
Memory & Expansion
The XCalibur1903 provides up to 8 GB of DDR3 ECC SDRAM, two XMC/PrPMC slots, and 512 MB of NOR flash (with redundancy).
I/O & Connectivity
It supports up to three 10/100/1000BASE-T Ethernet ports, PMC I/O, USB 2.0, optional SATA ports capable of 3 Gb/s, and RS-232/422/485 serial ports out backplane connectors.
Front Panel I/O
An optional front panel offers 10GBASE-T Ethernet, USB 2.0, and RS-232 serial. An additional 10GBASE-T Ethernet port to front panel using I/O mezzanine card is also optionally supported.
Software Support
The XCalibur1903 is a powerful, feature-rich solution for the next generation of compute-intensive embedded applications. Wind River VxWorks, Linux, and Green Hills INTEGRITY Board Support Packages (BSPs) are available.
Processor
- NXP QorIQ T2080 processor
- Four dual-threaded e6500 cores at 1.8 GHz
- 2 MB of shared L2 cache
Memory
- Up to 8 GB of DDR3 ECC SDRAM
- Up to 512 MB of NOR flash (with redundancy)
- Up to 32 GB of NAND flash
- NVMe storage (optional)
cPCI
- 66 MHz 32-bit PCI interface to J1 and J2
- PICMG 2.1 (Hot Swap support)
- PICMG 2.3 (PMC I/O to J3 and J5)
- PICMG 2.9 (dedicated IPMI controller)
- PICMG 2.16 (two 10/100/1000BASE-T Ethernet ports)
XMC/PrPMC
- PCI-X (64/32-bit, 100/66 MHz)
- PCI (64/32-bit, 66/33 MHz)
- x8 PCI Express interface to J15 and J25 (XMC)
Front Panel (Optional)
- Two RS-232 serial ports
- One 10GBASE-T Ethernet port
- One USB 2.0 port
- One 10GBASE-T Ethernet port to front panel using I/O mezzanine card
- General-purpose LEDs
Back Panel
- Two RS-232/422/485 serial ports
- Two 10/100/1000BASE-T Ethernet ports
- Two SATA ports capable of 3 Gb/s (optional, contact factory)
- Up to two USB 2.0 ports
- PMC I/O
IPMI
- Onboard management controller
Software Support
- Wind River VxWorks BSP
- Linux BSP
- Green Hills INTEGRITY-178 BSP
Environmental Requirements
Contact factory for appropriate board configuration based on environmental requirements.
- Supported ruggedization levels (see the X-ES Ruggedization Chart): 1, 5
- Conformal coating available as an ordering option
Power Requirements
- Power will vary based on configuration and usage. Please consult factory.
Accessories
- XIt4103 (90060165) – 6U cPCI RTM
- Cable (30075004) – Serial, Micro D to DB-9, F to M, 3 ft.
XCalibur1903
NXP QorIQ T2080 Processor-Based Conduction or Air-Cooled 6U cPCI Module
