3U VPX SINGLE BOARD COMPUTER · SKU 90030755
XPedite5972
The XPedite5972 is a 3U OpenVPX™ REDI single board computer based on the NXP QorIQ T2080 processor. It is a design refresh of the XPedite5970, intended to update obsolete components while maintaining the same functionality and features.
Product Lifecycle
Built with components rated for extreme conditions and validated through rigorous testing, our solutions minimize obsolescence risk and lower total cost of ownership across the full program lifespan.
Engineered for Extended Reliability
All X-ES products are designed and manufactured 100% in the USA with components from trusted supply chains in order to deliver rugged, reliable performance in the most demanding environments.
X-ES also offers comprehensive configuration management solutions that extend product support and availability beyond final sale, keeping systems running long after standard end-of-life milestones.
Introduction to XPedite5972
The XPedite5972 is a 3U OpenVPX™ REDI single board computer based on the NXP QorIQ T2080 processor.
It is a design refresh of the XPedite5970, intended to update obsolete components while maintaining the same functionality and features.
Ruggedized Performance
The XPedite5972 provides a rugged, feature-rich processing solution that maximizes the performance-per-watt capabilities of a Power Architecture®-based processor module.
The T2080 processor offers eight virtual (four dual-threaded) e6500 cores, running at up to 1.8 GHz, and integrates a 128-bit AltiVec technology-based SIMD engine per core.
DSP & Floating-Point Performance
The integrated AltiVec SIMD engines enable the XPedite5972 to support DSP-level Floating-Point performance and an extensive inventory of software libraries.
Memory & I/O
The XPedite5972 also supports up to 8 GB of DDR3 ECC SDRAM and provides a plethora of I/O options to the backplane, including 10 Gigabit Ethernet, PCI Express Gen3, and Gen2 SRIO.
Expansion Capabilities
The XPedite5972 provides superior growth and expansion capabilities by including an XMC or PMC site with full 10 mm I/O envelope support while maintaining a 0.8 in. VPX slot pitch, providing the system integrator with a wide variety of COTS options for additional I/O, storage, or processing while minimizing total system SWaP-C.
Software Support
Wind River VxWorks, Linux, Green Hills INTEGRITY, and DDC-I’s DO-178 Certifiable Deos Board Support Packages (BSPs) are available.
Processor
- NXP QorIQ T2080 processor
- Eight virtual (four dual-threaded) Power Architecture® e6500 cores at up to 1.8 GHz
- 2 MB L2 cache
- 512 kB platform cache
- IEEE 754 Floating-Point Unit (FPU) support
- 128-bit AltiVec technology-based SIMD engine
Memory
- Up to 8 GB of DDR3 ECC SDRAM
- Up to 512 MB of NOR flash (with redundancy)
- Up to 64 GB of NAND flash
XMC/PrPMC Site
- 32-bit, 66 MHz PCI bus (PMC interface)
- x4 PCI Express port (XMC interface)
- P64s P14 I/O support (optional)
- X12d P16 I/O support
Front Panel I/O
- Front panel RJ-45 Ethernet, micro-DB-9 RS-232 serial ports, and USB 2.0 available via optional plugover module
VPX (VITA 46) P0 I/O
- I²C port
VPX (VITA 46) P1 I/O
- x4 PCI Express, Serial RapidIO or 10 GbE XAUI Fat Pipe to P1.A
- x4 PCI Express or Serial RapidIO Fat Pipe to P1.B
- Two SerDes Gigabit Ethernet ports (or one 10/100/1000BASE-T port to P1 and one 10/100/1000BASE-T port to P2)
- X12d XMC P16 I/O
VPX (VITA 46) P2 I/O
- One 10/100/1000BASE-T port (when two SerDes Gigabit Ethernet P1 ports are not used)
- Two RS-232/422/485 serial ports
- Two USB 2.0 ports
- I²C port
- 3.3 V GPIO signals
- P64s PMC P14 I/O (optional)
- Two SATA ports capable of 6 Gb/s (optional)
Software Support
- Wind River VxWorks BSP
- Linux BSP
- Green Hills INTEGRITY-178 BSP
- DDC-I’s DO-178 Certifiable Deos BSP
- Contact factory for availability of QNX Neutrino and LynuxWorks LynxOS BSPs
Physical Characteristics
- 3U VPX-REDI conduction- or air-cooled form factor
- Dimensions: 100 mm x 160 mm
- 0.8 in. pitch without solder-side cover
- 0.85 and 1.0 in. pitch with solder-side cover
Environmental Requirements
Contact factory for appropriate board configuration based on environmental requirements.
- Supported ruggedization levels (see the X-ES Ruggedization Chart): 5
- Conformal coating available as an ordering option
- Contact X-ES for air-cooled development options
Power Requirements
- Power will vary based on configuration and usage. Please consult factory.
Accessories
- XIt1070 (90060170) – 3U VPX Rear Transition Module with Gigabit Ethernet, SATA, USB, Serial, and DVI
- XPand1007 (90075300) – Two-Slot 3U VPX Development Platform for Conduction-Cooled Modules with RTM I/O
- XPand1203 (90072665) – 3U VPX Development Platform for Up to Eight Conduction-Cooled Modules
- XPand1205 (90075035) – 3U VPX Development Platform for Up to Eight Conduction-Cooled Modules
- XTend214 (90071725) – Debug Module for NXP Processor-Based Boards
XPedite5972
NXP QorIQ T2080 Processor-Based Conduction- or Air-Cooled 3U VPX Single Board Computer
