3U VPX REAR TRANSITION MODULE · SKU 90060170
XIt1070
The XIt1070 provides I/O expansion for 3U VPX SBCs.
Product Lifecycle
X-ES also offers comprehensive configuration and obsolescence management services, providing customers with direct control over non-interchangeable changes and extending product availability and serviceability well beyond standard end-of-life milestones.
Engineered for Extended Reliability
All X-ES products are designed and manufactured 100% in the USA with components from trusted supply chains in order to deliver rugged, reliable performance in the most demanding environments.
Built with components rated for extreme conditions and validated through rigorous testing, our solutions minimize obsolescence risk and lower total cost of ownership across the full program lifespan.
Introduction to XIt1070
The XIt1070 provides I/O expansion for 3U VPX SBCs.
I/O Connectivity
The XIt1070 supports one RS-232/422/485 port, one RS-232 port, a SATA port, two 10/100/1000BASE-T ports, and a USB port in its default configuration.
Expansion I/O
When mated with the optional XIt1071, an additional SATA port and two Mini-HDMI (DVI) ports are also provided.
Back Panel I/O (Standard)
- Two RJ-45 connectors for dual 10/100/1000BASE-T ports
- One micro-DB-9 for dual serial ports
- One USB connector
- One eSATA connector
Alternate VPX Ethernet Configurations
- Two 10/100/1000BASE-T ports (one on RP1 and one on RP2)
- Two 1000BASE-BX ports (both on RP1)
Back Panel I/O (With Optional XIt1071)
- Additional eSATA connector
- Two Mini-HDMI connectors for dual DVI ports
Physical Characteristics
- 3U VPX form factor
- Mechanically compliant to VITA 46.10
- Dimensions: 100 mm x 81.5 mm
- 1.0 in. pitch
Environmental Requirements
Contact factory for appropriate board configuration based on environmental requirements.
- Supported ruggedization levels (see the X-ES Ruggedization Chart): 1
- Conformal coating available as an ordering option
Accessories
- XTend300 (90070180) – 1x Female DB-9 to 2x Male DB-9 Serial Port Converter
- Cable (30075004) – Serial, Micro D to DB-9, F to M, 3 ft.
- Cable (30075026) – Mini HDMI to HDMI, M to M, 2 Meter
- Cable (30075029) – Mini HDMI to DVI-D, M to M, 2 Meter
XIt1070
3U VPX Rear Transition Module with Gigabit Ethernet, SATA, USB, Serial, and DVI
