6U VME SINGLE BOARD COMPUTER · SKU 90055160
XCalibur5330
The XCalibur5330 is a secure, high-performance 6U VME single board computer based on the Intel® Core™ Ultra (Series 3) processor (formerly Panther Lake).
Ideal for ruggedized systems requiring high-bandwidth processing and low power consumption, the XCalibur5330 delivers superior performance and efficiency for today’s network information processing and high performance embedded computing applications.
Product Lifecycle
X-ES also offers comprehensive configuration and obsolescence management services, providing customers with direct control over non-interchangeable changes and extending product availability and serviceability well beyond standard end-of-life milestones.
Engineered for Extended Reliability
All X-ES products are designed and manufactured 100% in the USA with components from trusted supply chains in order to deliver rugged, reliable performance in the most demanding environments.
Built with components rated for extreme conditions and validated through rigorous testing, our solutions minimize obsolescence risk and lower total cost of ownership across the full program lifespan.
Introduction to XCalibur5330
The XCalibur5330 is a secure, high-performance 6U VME single board computer based on the Intel® Core™ Ultra (Series 3) processor (formerly Panther Lake).
Ruggedized Performance
Ideal for ruggedized systems requiring high-bandwidth processing and low power consumption, the XCalibur5330 delivers superior performance and efficiency for today’s network information processing and high performance embedded computing applications.
Security & Data Protection
The XCalibur5330 integrates SecureCOTS™ technology with a Microchip PolarFire™ System-on-Chip (SoC) FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required.
Memory & Storage
The XCalibur5330 supports up to 64 GB of LPDDR5 SDRAM with in-band ECC in eight channels and up to 1 TB of onboard NVMe storage, with optional AES-128/256 TCG Opal 2.0 Self-Encrypting Drive (SED) support.
I/O & Connectivity
The XCalibur5330 also provides fast and efficient I/O, including 10/100/1000BASE-T Ethernet, USB 2.0, PCI, DisplayPort++, and RS-232/422/485 serial ports through the backplane connectors.
An M.2 site and additional front-panel USB 2.0 and Ethernet interfaces are available by default, but are not available on configurations where XMC/PMC 0 connectors are populated.
Software Support
Wind River VxWorks, X-ES Enterprise Linux (XEL), and Linux Yocto Board Support Packages (BSPs) are available.
Processor
- Supports Intel® Core™ Ultra (Series 3) processors (formerly Panther Lake)
Memory
- Up to 64 GB of LPDDR5 SDRAM with in-band ECC
- Up to 1 TB of onboard NVMe storage with optional Self-Encrypting Drive (SED) offering AES-128/256 TCG Opal 2.0 hardware encryption support
- 64 MB NOR boot flash
- 64 kB EEPROM
Security and Management
- Microchip PolarFire™ SoC FPGA with 256 MB SPI NOR flash
- Designed with SecureCOTS™ technology to support enhanced security and trusted computing
- Trusted Platform Module (TPM) 2.0
Additional Features
- Non-volatile memory write protection
- DS1339 I²C Real-Time Clock (RTC) powered via VBAT or optional battery
VME
- VME64 (VITA 1-1994 R2002)
- VME64x (VITA 1.1-1997 R2003)
- 2eSST (VITA 1.5-2003)
- Ethernet on VME64x (VITA 31.1-2003)
- PMC I/O on VME (VITA 35-2000)
XMC/PMC
- 33/66 MHz 32-bit PCI interface to PMC connectors
- x4 PCI Express Gen4-capable interface to J15
- x8 PCI Express Gen4-capable interface to J25
Front Panel I/O
- One 10/100/1000BASE-T Ethernet interface
- Two additional 10/100/1000BASE-T Ethernet interfaces (default configuration but mutually exclusive placement with XMC/PMC 0)
- One USB 2.0 port
- Two additional USB 2.0 ports (default configuration but mutually exclusive placement with XMC/PMC 0)
- One DisplayPort++ HBR2-capable interface
Rear Panel I/O
- Two 10/100/1000BASE-T Ethernet interfaces (standard)
- One additional 10/100/1000BASE-T Ethernet interface (optional, mutually exclusive with optional front panel 10/100/1000BASE-T Ethernet interfaces)
- Two USB 2.0 ports
- Four RS-232/422/485 serial ports
- 3.3 V GPIO signals
- PMC I/O
Internal I/O
- One M.2 site to support one x2 PCI Express Gen4-capable interface (default configuration but mutually exclusive placement with XMC/PMC 0)
Software Support
- UEFI firmware
- Wind River VxWorks BSP
- X-ES Enterprise Linux (XEL) BSP
- Linux Yocto BSP
- Contact factory for availability of Microsoft Windows drivers and other operating systems
Physical Characteristics
- 6U VME air-cooled form factor
- Dimensions: 233 mm x 160 mm
Environmental Requirements
Contact factory for appropriate board configuration based on environmental requirements. Additional ruggedization levels may also be possible to support.
- Supported ruggedization levels (see the X-ES Ruggedization Chart): 1
- All components support junction temperatures of -40 to +85°C or greater
- Conformal coating available as an ordering option
- Thermal performance will vary based on CPU frequency and application
Power Requirements
- Power will vary based on configuration and usage. Please consult factory.
Accessories
- XIt1025 (90060490) – 6U VME I/O Transition Module for X-ES Single Board Computers
XCalibur5330
Intel® Core™ Ultra (Series 3) Processor-Based 6U VME Module with 64 GB of LPDDR5 and Microchip PolarFire™ SoC FPGA
