The XPedite6106 is a high-performance, XMC/PrPMC, single board computer supporting an NXP QorIQ T1042 processor and accommodating up to 8 GB of DDR3 ECC SDRAM. It is a design refresh of the XPedite6100, intended to update obsolete components while maintaining the same functionality and features.
The T1042 processor available in the XPedite6106’s default configuration offers four e5500 cores running at up to 1.4 GHz with a single channel of DDR3 memory, all within a low power envelope. When configured to use the T2081 processor, the XPedite6106 maximizes performance with eight virtual (four dual-threaded) e6500 cores running at up to 1.8 GHz. Each e6500 core implements the NXP AltiVec technology-based SIMD engine, providing DSP-level Floating-Point performance and an extensive inventory of software libraries. The T1022 provides the lowest power configuration with two e5500 cores running at up to 1.4 GHz.
The XPedite6106 provides 10/100/1000BASE-T Ethernet, USB 2.0, and RS-232 serial to the front panel. It supports I/O including 10/100/1000BASE-T Ethernet, USB 2.0, RS-232/422/485 serial and PCI Express to the mezzanine connectors. SATA support is not standard but may be available by request.
The XPedite6106 provides a high-performance, feature-rich solution for current and future generations of embedded applications. Linux and Wind River VxWorks Board Support Packages (BSPs) are available.
Technical Specs
Processor
- NXP QorIQ T1042 processor with four Power Architecture® e5500 cores at up to 1.4 GHz
- 256 kB back-side L2 cache (per core)
- 256 kB platform cache
- IEEE 754 Floating-Point Unit support
Alternate Processor Configurations
- T1022 (two e5500 cores) at up to 1.4 GHz
- T2081 (four dual-threaded e6500 cores) at up to 1.8 GHz
Memory
- Up to 8 GB of DDR3 ECC SDRAM
- Up to 512 MB of NOR flash (with redundancy)
- Up to 32 GB of NAND flash
PrPMC Interface
- 66/33 MHz PCI
- 32-bit bus interface
P15 XMC Interface
- x4 PCI Express Gen2 (T10xx) or Gen3 (T2081)
P14/P16 XMC/PMC Interfaces
- Two 10/100/1000BASE-T Ethernet ports to P14
- One 10/100/1000BASE-T Ethernet port to P16
- Two RS-232/422/485 serial ports
- 3.3 V GPIO
- Up to two USB 2.0 ports
- Two SATA ports capable of 6 Gb/s (optional, contact factory)
Front Panel I/O
- One 10/100/1000BASE-T Ethernet port
- Two RS-232 serial ports
- One USB 2.0 port
Software Support
- Linux BSP
- Wind River VxWorks BSP
Physical Characteristics
- Air-cooled XMC/PMC form factor
- Dimensions: 149 mm x 74 mm, 10 mm stacking height
Environmental Requirements
Contact factory for appropriate board configuration based on environmental requirements.
Power Requirements
- Power will vary based on configuration and usage. Please consult factory.
