XPedite7870

Intel® Xeon® D-2700 Processor-Based 3U VPX-REDI Module with 64 GB of DDR4, 40 Gigabit Ethernet, and SecureCOTS™

The XPedite7870 is a secure, high-performance, 3U VPX-REDI, single board computer based on the Intel® Xeon® D-2700 series (formerly Ice Lake-D) of processors.

The XPedite7870 is an optimal choice for computationally heavy applications requiring maximum data and information protection.

Learn more about this product below »
REQUEST A QUOTE ASK A QUESTION

Contact us directly at +1 (608) 833-1155

XPedite7870 3U VPX Single Board Computer (SBC)

The XPedite7870 is a secure, high-performance, 3U VPX-REDI, single board computer based on the Intel® Xeon® D-2700 series (formerly Ice Lake-D) of processors. The XPedite7870 is an optimal choice for computationally heavy applications requiring maximum data and information protection.

The XPedite7870 integrates SecureCOTS™ technology with a Microsemi® PolarFire™ FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required.

The XPedite7870 provides incredible speed with two 40GBASE-KR4 and one 10/100/1000BASE-T Ethernet ports. It accommodates up to 64 GB of DDR4 ECC SDRAM in four channels and up to 32 GB of onboard SLC NAND flash in addition to numerous I/O ports, including USB 2.0, PCIe, and RS-232/422/485 serial through the backplane connectors.

Wind River VxWorks and X-ES Enterprise Linux (XEL) Board Support Packages (BSPs) are available.

Features

  • Supports Intel® Xeon® D-2700 series (formerly Ice Lake-D) processors
  • Up to 20 Xeon®-class cores in a single, power-efficient SoC package
  • SKUs available with native extended temperature support
  • Designed with SecureCOTS™ technology to support enhanced security and trusted computing
  • Microsemi® PolarFire™ FPGA with 128 MB SPI flash
  • 3U VPX (VITA 46) module
  • Compatible with multiple VITA 65 OpenVPX™ slot profiles
  • Ruggedized Enhanced Design Implementation (REDI) per VITA 48
  • 64 GB of DDR4 ECC SDRAM in four channels
  • 32 GB of SLC NAND flash
  • Two 40GBASE-KR4 Ethernet ports
  • One 10/100/1000BASE-T Ethernet port
  • Two x4 Gen3, one x4 Gen2, and two x2 Gen2 PCIe interfaces
  • Two USB 2.0 ports
  • Two RS-232/422/485 serial ports
  • Wind River VxWorks BSP
  • X-ES Enterprise Linux (XEL) BSP
  • Contact factory for SATA, PCIe Gen4, or 100GBASE-KR4 availability
  • Contact factory for availability of Green Hills INTEGRITY, QNX Neutrino, and LynuxWorks LynxOS BSPs, as well as Microsoft Windows drivers

Technical Specs

Processor

  • Intel® Xeon® D-2700 series (formerly Ice Lake-D) processor
  • Up to 20 Xeon®-class cores in a single, power-efficient SoC package
  • SKUs available with native extended temperature support

Memory

  • 64 GB of DDR4 ECC SDRAM in four channels
  • 32 GB of SLC NAND flash
  • 64 MB NOR boot flash
  • 64 kB EEPROM

Security and Management

  • Microsemi® PolarFire™ FPGA with 128 MB SPI flash
  • Designed with SecureCOTS™ technology to support enhanced security and trusted computing
  • System voltage monitor, power-on/reset control, non-volatile write-protection control
  • Trusted Platform Module (TPM)

VPX (VITA 46) P1 I/O

  • Two 40GBASE-KR4 ports to P1.A and P1.B
  • One x4 PCI Express Gen3-capable interface to P1.C

VPX (VITA 46) P2 I/O

  • One 10/100/1000BASE-T Ethernet port
  • One x4 PCI Express Gen3-capable interface
  • One x4 PCI Express Gen2-capable interface
  • Two x2 PCI Express Gen2-capable interfaces
  • Two USB 2.0 ports
  • Two RS-232/422/485 serial ports
  • Four single-ended FPGA GPIOs

Software Support

  • UEFI firmware
  • Wind River VxWorks BSP
  • X-ES Enterprise Linux (XEL) BSP
  • Contact factory for availability of Green Hills INTEGRITY, QNX Neutrino, and LynuxWorks LynxOS BSPs, as well as Microsoft Windows drivers

Physical Characteristics

  • 3U VPX-REDI conduction- or air-cooled form factor
  • Dimensions: 100 mm x 160 mm
  • 0.8 in. pitch without solder-side cover
  • 1.0 in. pitch with Two-Level Maintenance (2LM) support

Environmental Requirements

Contact factory for appropriate board configuration based on environmental requirements

  • Supported ruggedization levels (see the X-ES Ruggedization Chart): 5
  • Conformal coating available as an ordering option
  • Thermal performance will vary based on CPU frequency and application
  • Contact X-ES for air-cooled development options

Power Requirements

  • Power will vary based on configuration and usage. Please consult factory.

Accessories

  • XIt1098 (90030650) - 3U VPX Rear Transition Module with Dual 40 Gigabit and 10 Gigabit Ethernet, USB, and Serial
  • XPand1200 (90070530) - 3U VPX Conduction-Cooled Development Platform
  • XTend218 (90072500) - Debug Module/Cable with Serial/I2C/USB/JTAG/SPI and Power Supply Programming

Documentation

Datasheet

To view all of the information about this product in a PDF, please download the datasheet.

Download Datasheet

Technical Documents

SupportNet is your source for product manuals, technical support, and software downloads.

Access SupportNet

Block Diagram
